Hastelloy B3

Additional information

UNS Number

N10675

Werkstoff Number

2.4600

Description

Hastelloy B3 is an additional member of the nickel-molybdenum family of alloys with excellent resistance to hydrochloric acid at all concentrations and temperatures. It also withstands sulfuric, acetic, formic and phosphoric acids, and other non-oxidizing media.Hastelloy B3 is Nickel-Molybdenum Alloy similar to Hastelloy B2 in terms of Resistance to Non Oxidizing agents, resistance to stress corrosion & pittings, non formationof grain boundry but was designed with addition quality of Thermal stability which improves welding preparations.

Hastelloy B3 has a special chemistry designed to achieve a level of thermal stability greatly superior to that of it predecessors, e.g. Hastelloy B2 .

Application

Hastelloy B3 is widely used in the chemical, petrochemical, energy manufacturing and pollution control related processing and equipment , especially in the processes dealing with various acids  Some of the more common uses including:

  • Gasoline and freshwater tanks.
  • Crude petroleum stills.
  • Pumps, shafts and fasteners.
  • Industrial heat exchangers.
  • Chlorinated solvents.
  • Crude oil distillation towers.
  • Oil refinery piping.
  • Generator tubing.

Chemical Component

Chemical Components Fe C Si Mn P S Cr Ni Cu Mo Ti W V Nb Zr Co Al
Minimum 1 1 65 27 Ni+Mo:94-98; Ta≤0.2
Maximum 3 0.01 0.1 3 0.03 0.01 3 0.2 32 0.2 3 0.2 0.2 0.1 3 0.5

Mechanical Properties

Tensile Strength
σb
Mpa
Yield Point
σs
Mpa
Elongation
δ
%
Hardness

HBW

≥750 ≥340 ≥40 ≤240

Product Form

Product Form Size Range From Size Range To
Sheet & Plate 0.30 mm 25 mm
Round Bar 4 mm 380 mm
Tube 6 mm 260 mm
