Hastelloy C 276

Additional information

UNS Number

N10276

Werkstoff Number

2.4819

Description

Hastelloy C-276 (also known as Alloy C-276), is a nickel-molybdenum-chromium-iron-tungsten alloy which is among the most corrosion-resistant alloys currently available. The high molybdenum content imparts resistance to localized corrosion such as pitting. The low carbon minimizes carbide precipitation during welding to maintain resistance to intergranular attack in heat affected zones of welding joints.

Typical applications of HASTELLOY C276 include equipment components in chemical and petrochemical organic chloride processes and processes utilizing halide or acid catalysts. … HASTELLOY C-276 is a nickel-chromium-molybdenum alloy with universal corrosion resistance unmatched by any other alloy.

Application

Hastelloy C 276 can be used in a variety of applications including:

  • Gas Air Pollution Control – flue gas desulfurization systems – stack liners, absorbers, ducts, dampers, stack gas re-heaters and fans
  • Chemical Processing – heat exchangers, pressure vessels, tanks, evaporators, piping, flanges and fittings, pumps and valves
  • Oil and Gas Production – sour gas service components
  • Pharmaceutical Production – reactor vessels, piping, flanges and fittings, pumps and valves
  • Pulp and Paper – bleaching vessels and digesters
  • Waste Treatment – incinerators for toxic, industrial and municipal waste

Chemical Component

Chemical Components Fe C Si Mn P S Cr Mo W V Co Ni
Minimum 4 14.5 15 3 Ba
Maximum 7 0.01 0.08 1 0.04 0.03 16.5 17 4.5 0.35 2.5

Mechanical Properties

Tensile Strength
σb
ksi
Yield Point
σs
ksi
Elongation
δ
%
Hardness

HBW

110-140 ≥45 ≥25 HRC

20-32



Product Form

Product Form Size Range From Size Range To
Sheet & Plate 0.30 mm 25 mm
Round Bar 4 mm 380 mm
Tube 6 mm 260 mm

Request a Quote
