Incoloy 330

Additional information

UNS Number

N08330

Werkstoff Number

1.4886

Description

INCOLOY alloy 330 is an alloy comprising of nickel-iron-chromium with silicon as an additive. Using silicon as an additive gives the alloy enhanced oxidation resistance. This alloy exhibits good strength at high temperatures and good resistance to oxidation and reduction environments. Its oxidation resistance is enhanced by the silicon content. The microstructure of the alloy maintains its stability even after being exposed to high temperatures for long durations. it a useful material for industrial heating furnaces; for muffles, retorts, conveyor systems, baskets and boxes, and various fixtures.

Application

  • Chemical and Petrochemical Processing

– Cracked ammonia components

– Petrochemical furnace parts

– Petrochemical waste remediation units

– Heat exchangers

– Flares

  • Ore Processing

– Perlite systems and equipment

  • Power Generation

– Boiler fixtures

– Gas turbine components

  • Thermal Processing

– Heat-treat furnace containers

– Heat-treat furnace components

– High temperature fans

– Salt pots

Chemical Component

Chemical Components C Si Mn P S Cr Ni Cu Pb Sn Fe
Minimum 0.75 17 34 Ba
Maximum 0.08 1.5 2 0.03 0.03 20 37 1 0.005 0.025

Mechanical Properties

Tensile Strength
σb
Mpa
Yield Point
σs
Mpa
Elongation
δ
%
Hardness

HBW

≥483 ≥207 long.
≥30
70-90

Product Form

Product Form Size Range From Size Range To
Sheet & Plate 0.30 mm 25 mm
Round Bar 4 mm 380 mm
Tube 6 mm 260 mm
