Inconel 600

Additional information

UNS Number

N06600

Werkstoff Number

2.4816

Description

Inconel 600 is a nickel-based metal alloy that is known for its resistance to heat and corrosion. In addition to nickel, it also has relatively high amounts of iron, cobalt and chromium.

Inconel 600 is an extremely corrosion resistant material. The high amounts of nickel in Inconel 600 give it the ability to resist corrosion, and in particular, chloride stress corrosion. So it’s a popular material choice for applications in the chemical industry.Inconel 600 is also able to resist heat exceptionally well. This makes it very popular in heat exchange and heat treatment applications, making it a popular choice in engine components, particularly those in the aerospace industry. It can withstand the temperatures found in cryogenic applications up to 2,000°F (1,093°C).

Application

  • Aerospace Components
  • Chemical Processing

– Chlorination equipment, fatty acids, hydrogen fluoride, magnesium chloride, vinyl chloride monomer, sodium sulfide, titanium dioxide

  • Petrochemical Processing- catalyst regenerators
  • Power Generation-nuclear components
  • Pulp and Paper-abietic acid equipment
  • Thermal Processing

– Baskets and trays, boxes, muffles and retorts, nitriding containers, roller hearths, vacuum furnace components

Chemical Component

Chemical Components C Si Mn S Cr Ni Cu Co
Minimum 14 72 Ni+Co≥72
Maximum 0.15 0.5 1 0.015 17 0.5 1.5



Mechanical Properties

Tensile Strength
σb
Mpa
Yield Point
σs
Mpa
Elongation
δ
%
Mpa

≥550

Mpa

≥240

≥30

Product Form

Product Form Size Range From Size Range To
Sheet & Plate 0.30 mm 25 mm
Round Bar 4 mm 380 mm
Tube 6 mm 260 mm
