Inconel 625

Additional information

UNS Number

N06625

Werkstoff Number

2.4856

Description

Inconel 625 demonstrates an excellent combination of corrosion resistance and high strength. Due to the high nickel content, it is immune to chloride-induced stress corrosion cracking. It also has good resistance to pitting and crevice corrosion.Inconel 625 is a high-performance nickel-chromium-molybdenum alloy known for its high level of strength, temperature resistance, and corrosion resistance. This superalloy is composed mainly of nickel (≥58% ) followed by chromium, and molybdenum, niobium, iron, tantalum, cobalt, and trace amounts of manganese, silicon, aluminium, and titanium. The strength of Inconel 625 is derived from the solid-solution hardening of the nickel-chromium matrix by the presence of molybdenum and niobium. Therefore, precipitation-hardening treatments are not required.

Inconel 625 also commonly goes by the names: Haynes 625, Altemp 625, Nickelvac 625, and Nicrofer 6020.

Application

Inconel 625 can be used in a variety of applications including:

  • Aircraft ducting and exhaust systems
  • Engine thrust-reverser systems
  • Turbine shroud rings
  • Bellows, expansion joints
  • Gaskets and damper seals
  • Motorsport exhaust and clamps
  • Weld overlay and spacers for heat recovery systems
  • Furnace muffles
  • Valve seats and components

Chemical Component

Chemical Components Fe C Si Mn P S Cr Ni Cu Mo Ti Nb Al
Minimum 20 58 1.3 8 3.15 Nb+Ta:

3.15~4.15

Maximum 5 0.1 0.5 0.5 0.015 0.015 23 1.9 10 0.4 4.15 0.4

Mechanical Properties

Tensile Strength
σb
ksi
Yield Point
σs
ksi
Elongation
δ
%
Hardness

HBW

≥120 ≥60 ≥30 85HRB-35HRC

Product Form

Product Form Size Range From Size Range To
Sheet & Plate 0.30 mm 25 mm
Round Bar 4 mm 380 mm
Tube 6 mm 260 mm
