Inconel X-750

Inconel X-750

Additional information

UNS Number

N07750

Werkstoff Number

2.4669

Description

Inconel X-750 is a precipitation-hardenable nickel-chromium alloy used for its corrosion and oxidation resistance and high strength at temperatures to 1300°F. Although much of the effect of precipitation hardening is lost with increasing temperature over 1300°F, heat-treated material has useful strength up to 1800°F. Inconel X-750 also has excellent properties down to cryogenic termperatures.

Inconel X-750 is used extensively in rocket-engine thrust chambers. Airframe applications include thrust reversers and hot-air ducting systems. Large pressure vessels are formed from Inconel X-750. Other applications are heat-treating fixtures, forming tools, extrusion dies, and test machine grips.

Application

Inconel X-750 can be used in a variety of applications including:

  • Gas turbines and turbine blades, seals, and rotors
  • Bolts
  • Forming tools
  • Extrusion dies
  • Heat treating and nuclear reactor applications

Chemical Component

Chemical Components Fe C Si Mn S Cr Ni Cu Ti Nb Co Al
Minimum 5 14 70 2.25 0.5 0.4 Nb+Ta:

0.7~1.2

Maximum 9 0.08 0.5 1 0.01 17 0.5 2.75 2.5 1 1

Mechanical Properties

Tensile Strength
σb
Mpa
Yield Point
σs
Mpa
Elongation
δ
%
Section Shrinkage

ψ

%

Impact Strength

KV2

J

1000-1200 ≥650 ≥20 ≥28 ≥22

Product Form

Product Form Size Range From Size Range To
Sheet & Plate 0.30 mm 25 mm
Round Bar 4 mm 380 mm
Tube 6 mm 260 mm
